规格 | 参数 | enec specifications | parameter |
洗涤加热方式 | 蒸汽或电加热 | Washingheatingmode | Steamorelectricheating |
最大洗涤量 | >200筐 | Maximum washing capacity | >200backetsperhour |
最大洗涤高度 | 300MM | Maximum washing height | 300MM |
耗水量 | 350-400L | Water consumption | 350-400L |
水箱容积 | 84L | The tank volume | 84L |
洗涤温度 | 60-80℃ | Washing temperature | 60-80℃ |
漂洗温度 | 60-80℃ | Rinse temperature | 65-80℃ |
洗涤周期 | 120-150s | The washing cycle | 120-150s |
排水管径 | DN50 | Drainage pipe diameter | DN50 |
进水管径 | DN15 | The water pipe diameter | DN15 |
电气总功率 | 62.65K | Total electrical power | 62.65K |
蒸汽总功率 | 2.65Kw | Totalsteampower | 2.65KW |
产品规格 | 2200*720*1600 | Product specification | 220*720*1600 |
PF-200的工作方式是入口处的人把待洗的餐具放到洗碗机的清洗入口处洗碗机会自动清洗
◆豪华外观,全食品级304不锈钢制造,凡与餐具接触的部分由无毒、耐热、耐腐蚀的材料制成,不会损 坏餐具,完全符合国家的卫生材料。
◆多洗涤槽,加长洗涤臂,一次主喷淋,一道清水冲洗
◆工作程序采用微电脑集中控制,大屏幕蓝色背光中文液品显示,操作一目了然
◆倾斜的圆弧角洗涤槽结构,可拆装的洗涤,使设备清洗更容易,高
◆机器集成干燥剂,洗涤剂分配器,加入干燥剂便可快速干燥碗碟;高温82℃以上热水漂洗,消毒更彻 底,符合餐具卫生消毒要
◆以上参数以6寸盘为举例说明,以实际情况为准
◆图片仅供参考,以实物为准
PF-200's way of working is that people at the entrance put the dishes to be washed into the dishwasher
◆ luxury appearance, all-food grade 304 stainless steel manufacture, all parts in contact with tableware made of non-toxic, heat-resistant, corrosion-resistant materials, will not damage the tableware, fully in line with the national sanitary materials.
◆ multiple sinks, lengthening arm, primary spray, flush with water
◆ working procedures using microcomputer centralized control, large screen blue backlight Chinese liquid display, operation at a glance
◆ inclined arc angle sink structure, detachable washing, make equipment cleaning easier and higher
◆ machine integrated desiccant, detergent distributor, add desiccant can quickly dry dishes; high temperature more than 82℃ hot water rinsing, disinfection more thorough, in line with tableware hygiene disinfection should be
◆ the above parameters to 6 inch disk as an example, the actual situation shall prevail
◆ picture is for reference only, subject to physical object
